Taramps Bilforsterker 4x200W 2 ohm

Taramps Bilforsterker DS 800x4, 2 ohm 4x200W

DS800X2 er en digital 4-kanals forsterker på hele 200 Watt RMS pr kanal i 2 Ohm. Du kan også brokoble  og kjøre den som en 2 kanaler på 400 Watt RMS.

Spesifikasjoner

• Operation class: Class D
• Number of Channels: 04
• Maximum power: @ 12.6 VDC - 2 OHMS: 800W RMS (4 x 200W RMS)
                                @ 12.6 VDC - 4 OHMS: 544W RMS (4 x 136W RMS)
                                 2 channels bridged - 2 OHMS: 800WRMS (2 x 400WRMS)
• Input Sensitivity: 250mV
• Signal to Noise Ratio: >88dB
• Frequency Response: 10Hz to 36KHz (-3dB)
• Crossover high pass (HPF): 90Hz (-12dB/8ª) Fixed
• Crossover low pass (LPF): 90Hz (-12dB/8ª) Fixed
• Input Impedance: 18K Ohms
• Output Impedance: 2 Ohms
• Protection system: Output overload
• Min. Supply Voltage: 9VDC
• Maximum Power Supply Voltage: 16VDC
• Consumption at rest: 1.4A
• Maximum music consumption: @12.6VDC: 43A
• Maximum consumption in sinusoidal signal: 86A
• Dimensions (WxHxD): 173 x 52 x 227 mm
• Weight: 1,43 kg
